Vision DataModules¶

The following are pre-built datamodules for computer-vision.

Supervised learning¶

These are standard vision datasets with the train, test, val splits pre-generated in DataLoaders with the standard transforms (and Normalization) values

BinaryEMNIST¶

class pl_bolts.datamodules.binary_emnist_datamodule.BinaryEMNISTDataModule(data_dir=None, split='mnist', val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, strict_val_split=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.emnist_datamodule.EMNISTDataModule

Please see EMNISTDataModule for more details.

Example:

from pl_bolts.datamodules import BinaryEMNISTDataModule
dm = BinaryEMNISTDataModule('.')
model = LitModel()
Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data.
split¶ (str) – The dataset has 6 different splits: byclass, bymerge, balanced, letters, digits and mnist. This argument is passed to torchvision.datasets.EMNIST.
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split.
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If True, applies image normalize.
batch_size¶ (int) – How many samples per batch to load.
seed¶ (int) – Random seed to be used for train/val/test splits.
shuffle¶ (bool) – If True, shuffles the train data every epoch.
pin_memory¶ (bool) – If True, the data loader will copy Tensors into CUDA pinned memory before returning them.
drop_last¶ (bool) – If True, drops the last incomplete batch.
strict_val_split¶ (bool) – If True, uses the validation split defined in the paper and ignores val_split. Note that it only works with "balanced", "digits", "letters", "mnist" splits.

dataset_cls[source]¶: alias of pl_bolts.datasets.emnist_dataset.BinaryEMNIST

BinaryMNIST¶

class pl_bolts.datamodules.binary_mnist_datamodule.BinaryMNISTDataModule(data_dir=None, val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.vision_datamodule.VisionDataModule

Specs:

10 classes (1 per digit)
Each image is (1 x 28 x 28)

Binary MNIST, train, val, test splits and transforms

Transforms:

mnist_transforms = transform_lib.Compose([
    transform_lib.ToTensor()
])

Example:

from pl_bolts.datamodules import BinaryMNISTDataModule

dm = BinaryMNISTDataModule('.')
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If true applies image normalize
batch_size¶ (int) – How many samples per batch to load
seed¶ (int) – Random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the train data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

dataset_cls[source]¶: alias of pl_bolts.datasets.mnist_dataset.BinaryMNIST

default_transforms()[source]¶

Default transform for the dataset.

Return type: Callable

property num_classes: int[source]¶

Return: 10

Return type: int

CityScapes¶

class pl_bolts.datamodules.cityscapes_datamodule.CityscapesDataModule(data_dir, quality_mode='fine', target_type='instance', num_workers=0, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, train_transforms=None, val_transforms=None, test_transforms=None, target_transforms=None, *args, **kwargs)[source]¶

Bases: pytorch_lightning.core.datamodule.LightningDataModule

Warning

The feature CityscapesDataModule is currently marked under review. The compatibility with other Lightning projects is not guaranteed and API may change at any time. The API and functionality may change without warning in future releases. More details: https://lightning-bolts.readthedocs.io/en/latest/stability.html

Standard Cityscapes, train, val, test splits and transforms

Note: You need to have downloaded the Cityscapes dataset first and provide the path to where it is saved.

You can download the dataset here: https://www.cityscapes-dataset.com/

Specs:

30 classes (road, person, sidewalk, etc…)
(image, target) - image dims: (3 x 1024 x 2048), target dims: (1024 x 2048)

Transforms:

transforms = transform_lib.Compose([
    transform_lib.ToTensor(),
    transform_lib.Normalize(
        mean=[0.28689554, 0.32513303, 0.28389177],
        std=[0.18696375, 0.19017339, 0.18720214]
    )
])

Example:

from pl_bolts.datamodules import CityscapesDataModule

dm = CityscapesDataModule(PATH)
model = LitModel()

Trainer().fit(model, datamodule=dm)

Or you can set your own transforms

Example:

dm.train_transforms = ...
dm.test_transforms = ...
dm.val_transforms  = ...
dm.target_transforms = ...

Parameters

data_dir¶ (str) – where to load the data from path, i.e. where directory leftImg8bit and gtFine or gtCoarse are located
quality_mode¶ (str) – the quality mode to use, either ‘fine’ or ‘coarse’
target_type¶ (str) – targets to use, either ‘instance’ or ‘semantic’
num_workers¶ (int) – how many workers to use for loading data
batch_size¶ (int) – number of examples per training/eval step
seed¶ (int) – random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

test_dataloader()[source]¶

Cityscapes test set.

Return type: DataLoader

train_dataloader()[source]¶

Cityscapes train set.

Return type: DataLoader

val_dataloader()[source]¶

Cityscapes val set.

Return type: DataLoader

property num_classes: int[source]¶

Return: 30

Return type: int

CIFAR-10¶

class pl_bolts.datamodules.cifar10_datamodule.CIFAR10DataModule(data_dir=None, val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.vision_datamodule.VisionDataModule

Specs:

10 classes (1 per class)
Each image is (3 x 32 x 32)

Standard CIFAR10, train, val, test splits and transforms

Transforms:

transforms = transform_lib.Compose([
    transform_lib.ToTensor(),
    transforms.Normalize(
        mean=[x / 255.0 for x in [125.3, 123.0, 113.9]],
        std=[x / 255.0 for x in [63.0, 62.1, 66.7]]
    )
])

Example:

from pl_bolts.datamodules import CIFAR10DataModule

dm = CIFAR10DataModule(PATH)
model = LitModel()

Trainer().fit(model, datamodule=dm)

Or you can set your own transforms

Example:

dm.train_transforms = ...
dm.test_transforms = ...
dm.val_transforms  = ...

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If true applies image normalize
batch_size¶ (int) – How many samples per batch to load
seed¶ (int) – Random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the train data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

dataset_cls[source]¶: alias of torchvision.datasets.cifar.CIFAR10

default_transforms()[source]¶

Default transform for the dataset.

Return type: Callable

property num_classes: int[source]¶

Return: 10

Return type: int

EMNIST¶

class pl_bolts.datamodules.emnist_datamodule.EMNISTDataModule(data_dir=None, split='mnist', val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, strict_val_split=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.vision_datamodule.VisionDataModule

Dataset information (source: EMNIST: an extension of MNIST to handwritten letters [Table-II])¶
Split Name	No. classes	Train set size	Test set size	Validation set	Total size
`"byclass"`	62	697,932	116,323	No	814,255
`"byclass"`	62	697,932	116,323	No	814,255
`"bymerge"`	47	697,932	116,323	No	814,255
`"balanced"`	47	112,800	18,800	Yes	131,600
`"digits"`	10	240,000	40,000	Yes	280,000
`"letters"`	37	88,800	14,800	Yes	103,600
`"mnist"`	10	60,000	10,000	Yes	70,000

Parameters

data_dir¶ (Optional[str]) – Root directory of dataset.
split¶ (str) – The dataset has 6 different splits: byclass, bymerge, balanced, letters, digits and mnist. This argument is passed to torchvision.datasets.EMNIST.
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split.
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If True, applies image normalize.
batch_size¶ (int) – How many samples per batch to load.
seed¶ (int) – Random seed to be used for train/val/test splits.
shuffle¶ (bool) – If True, shuffles the train data every epoch.
pin_memory¶ (bool) – If True, the data loader will copy Tensors into CUDA pinned memory before returning them.
drop_last¶ (bool) – If True, drops the last incomplete batch.
strict_val_split¶ (bool) – If True, uses the validation split defined in the paper and ignores val_split. Note that it only works with "balanced", "digits", "letters", "mnist" splits.

Here is the default EMNIST, train, val, test-splits and transforms.

Transforms:

emnist_transforms = transform_lib.Compose([
    transform_lib.ToTensor(),
])

Example:

from pl_bolts.datamodules import EMNISTDataModule

dm = EMNISTDataModule('.')
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If true applies image normalize
batch_size¶ (int) – How many samples per batch to load
seed¶ (int) – Random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the train data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch
train_transforms¶ – transformations you can apply to train dataset
val_transforms¶ – transformations you can apply to validation dataset
test_transforms¶ – transformations you can apply to test dataset

dataset_cls[source]¶: alias of torchvision.datasets.mnist.EMNIST

default_transforms()[source]¶

Default transform for the dataset.

Return type: Callable

prepare_data(*args, **kwargs)[source]¶

Saves files to data_dir.

Return type: None

setup(stage=None)[source]¶

Creates train, val, and test dataset.

Return type: None

property num_classes: int[source]¶

Returns the number of classes.

See the table above.

Return type: int

FashionMNIST¶

class pl_bolts.datamodules.fashion_mnist_datamodule.FashionMNISTDataModule(data_dir=None, val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.vision_datamodule.VisionDataModule

Parameters

data_dir¶ (Optional[str]) – Root directory of dataset.
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split.
num_workers¶ (int) – Number of workers to use for loading data.
normalize¶ (bool) – If True, applies image normalization.
batch_size¶ (int) – Number of samples per batch to load.
seed¶ (int) – Random seed to be used for train/val/test splits.
shuffle¶ (bool) – If True, shuffles the train data every epoch.
pin_memory¶ (bool) – If True, the data loader will copy Tensors into CUDA pinned memory before returning them.
drop_last¶ (bool) – If True, drops the last incomplete batch.

Specs:

10 classes (1 per type)
Each image is (1 x 28 x 28)

Standard FashionMNIST, train, val, test splits and transforms

Transforms:

mnist_transforms = transform_lib.Compose([
    transform_lib.ToTensor()
])

Example:

from pl_bolts.datamodules import FashionMNISTDataModule

dm = FashionMNISTDataModule('.')
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If true applies image normalize
batch_size¶ (int) – How many samples per batch to load
seed¶ (int) – Random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the train data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch
train_transforms¶ – transformations you can apply to train dataset
val_transforms¶ – transformations you can apply to validation dataset
test_transforms¶ – transformations you can apply to test dataset

dataset_cls[source]¶: alias of torchvision.datasets.mnist.FashionMNIST

default_transforms()[source]¶

Default transform for the dataset.

Return type: Callable

property num_classes: int[source]¶

Returns the number of classes.

Return type: int

Imagenet¶

class pl_bolts.datamodules.imagenet_datamodule.ImagenetDataModule(data_dir, meta_dir=None, num_imgs_per_val_class=50, image_size=224, num_workers=0, batch_size=32, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pytorch_lightning.core.datamodule.LightningDataModule

Warning

The feature ImagenetDataModule is currently marked under review. The compatibility with other Lightning projects is not guaranteed and API may change at any time. The API and functionality may change without warning in future releases. More details: https://lightning-bolts.readthedocs.io/en/latest/stability.html

Specs:

1000 classes
Each image is (3 x varies x varies) (here we default to 3 x 224 x 224)

Imagenet train, val and test dataloaders.

The train set is the imagenet train.

The val set is taken from the train set with num_imgs_per_val_class images per class. For example if num_imgs_per_val_class=2 then there will be 2,000 images in the validation set.

The test set is the official imagenet validation set.

Example:

from pl_bolts.datamodules import ImagenetDataModule

dm = ImagenetDataModule(IMAGENET_PATH)
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (str) – path to the imagenet dataset file
meta_dir¶ (Optional[str]) – path to meta.bin file
num_imgs_per_val_class¶ (int) – how many images per class for the validation set
image_size¶ (int) – final image size
num_workers¶ (int) – how many data workers
batch_size¶ (int) – batch_size
shuffle¶ (bool) – If true shuffles the data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

prepare_data()[source]¶

This method already assumes you have imagenet2012 downloaded. It validates the data using the meta.bin.

Warning

Please download imagenet on your own first.

Return type: None

test_dataloader()[source]¶

Uses the validation split of imagenet2012 for testing.

Return type: DataLoader

train_dataloader()[source]¶

Uses the train split of imagenet2012 and puts away a portion of it for the validation split.

Return type: DataLoader

train_transform()[source]¶

The standard imagenet transforms.

transform_lib.Compose([
    transform_lib.RandomResizedCrop(self.image_size),
    transform_lib.RandomHorizontalFlip(),
    transform_lib.ToTensor(),
    transform_lib.Normalize(
        mean=[0.485, 0.456, 0.406],
        std=[0.229, 0.224, 0.225]
    ),
])

Return type: Callable

val_dataloader()[source]¶

Uses the part of the train split of imagenet2012 that was not used for training via num_imgs_per_val_class

Parameters

batch_size¶ – the batch size
transforms¶ – the transforms

Return type

DataLoader

val_transform()[source]¶

The standard imagenet transforms for validation.

transform_lib.Compose([
    transform_lib.Resize(self.image_size + 32),
    transform_lib.CenterCrop(self.image_size),
    transform_lib.ToTensor(),
    transform_lib.Normalize(
        mean=[0.485, 0.456, 0.406],
        std=[0.229, 0.224, 0.225]
    ),
])

Return type: Callable

property num_classes: int[source]¶

Return:

1000

Return type: int

MNIST¶

class pl_bolts.datamodules.mnist_datamodule.MNISTDataModule(data_dir=None, val_split=0.2, num_workers=0, normalize=False, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pl_bolts.datamodules.vision_datamodule.VisionDataModule

Specs:

10 classes (1 per digit)
Each image is (1 x 28 x 28)

Standard MNIST, train, val, test splits and transforms

Transforms:

mnist_transforms = transform_lib.Compose([
    transform_lib.ToTensor()
])

Example:

from pl_bolts.datamodules import MNISTDataModule

dm = MNISTDataModule('.')
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – Where to save/load the data
val_split¶ (Union[int, float]) – Percent (float) or number (int) of samples to use for the validation split
num_workers¶ (int) – How many workers to use for loading data
normalize¶ (bool) – If true applies image normalize
batch_size¶ (int) – How many samples per batch to load
seed¶ (int) – Random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the train data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

dataset_cls[source]¶: alias of torchvision.datasets.mnist.MNIST

default_transforms()[source]¶

Default transform for the dataset.

Return type: Callable

property num_classes: int[source]¶

Return: 10

Return type: int

Semi-supervised learning¶

The following datasets have support for unlabeled training and semi-supervised learning where only a few examples are labeled.

Imagenet (ssl)¶

class pl_bolts.datamodules.ssl_imagenet_datamodule.SSLImagenetDataModule(data_dir, meta_dir=None, num_workers=0, batch_size=32, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pytorch_lightning.core.datamodule.LightningDataModule

Warning

The feature SSLImagenetDataModule is currently marked under review. The compatibility with other Lightning projects is not guaranteed and API may change at any time. The API and functionality may change without warning in future releases. More details: https://lightning-bolts.readthedocs.io/en/latest/stability.html

prepare_data_per_node[source]¶: If True, each LOCAL_RANK=0 will call prepare data. Otherwise only NODE_RANK=0, LOCAL_RANK=0 will prepare data.

allow_zero_length_dataloader_with_multiple_devices[source]¶: If True, dataloader with zero length within local rank is allowed. Default value is False.

prepare_data()[source]¶

Use this to download and prepare data. Downloading and saving data with multiple processes (distributed settings) will result in corrupted data. Lightning ensures this method is called only within a single process, so you can safely add your downloading logic within.

Warning

DO NOT set state to the model (use setup instead) since this is NOT called on every device

Example:

def prepare_data(self):
    # good
    download_data()
    tokenize()
    etc()

    # bad
    self.split = data_split
    self.some_state = some_other_state()

In a distributed environment, prepare_data can be called in two ways (using prepare_data_per_node)

Once per node. This is the default and is only called on LOCAL_RANK=0.
Once in total. Only called on GLOBAL_RANK=0.

Example:

# DEFAULT
# called once per node on LOCAL_RANK=0 of that node
class LitDataModule(LightningDataModule):
    def __init__(self):
        super().__init__()
        self.prepare_data_per_node = True


# call on GLOBAL_RANK=0 (great for shared file systems)
class LitDataModule(LightningDataModule):
    def __init__(self):
        super().__init__()
        self.prepare_data_per_node = False

This is called before requesting the dataloaders:

model.prepare_data()
initialize_distributed()
model.setup(stage)
model.train_dataloader()
model.val_dataloader()
model.test_dataloader()
model.predict_dataloader()

Return type: None

test_dataloader(num_images_per_class, add_normalize=False)[source]¶

Implement one or multiple PyTorch DataLoaders for testing.

For data processing use the following pattern:

download in prepare_data()

process and split in setup()

However, the above are only necessary for distributed processing.

Warning

do not assign state in prepare_data

test()
prepare_data()
setup()

Note

Lightning adds the correct sampler for distributed and arbitrary hardware. There is no need to set it yourself.

Return type: DataLoader
Returns: A torch.utils.data.DataLoader or a sequence of them specifying testing samples.

Example:

def test_dataloader(self):
    transform = transforms.Compose([transforms.ToTensor(),
                                    transforms.Normalize((0.5,), (1.0,))])
    dataset = MNIST(root='/path/to/mnist/', train=False, transform=transform,
                    download=True)
    loader = torch.utils.data.DataLoader(
        dataset=dataset,
        batch_size=self.batch_size,
        shuffle=False
    )

    return loader

# can also return multiple dataloaders
def test_dataloader(self):
    return [loader_a, loader_b, ..., loader_n]

Note

If you don’t need a test dataset and a test_step(), you don’t need to implement this method.

Note

In the case where you return multiple test dataloaders, the test_step() will have an argument dataloader_idx which matches the order here.

train_dataloader(num_images_per_class=- 1, add_normalize=False)[source]¶

Implement one or more PyTorch DataLoaders for training.

Return type: DataLoader
Returns: A collection of torch.utils.data.DataLoader specifying training samples. In the case of multiple dataloaders, please see this section.

The dataloader you return will not be reloaded unless you set reload_dataloaders_every_n_epochs to a positive integer.

For data processing use the following pattern:

download in prepare_data()

process and split in setup()

However, the above are only necessary for distributed processing.

Warning

do not assign state in prepare_data

fit()
prepare_data()
setup()

Note

Lightning adds the correct sampler for distributed and arbitrary hardware. There is no need to set it yourself.

Example:

# single dataloader
def train_dataloader(self):
    transform = transforms.Compose([transforms.ToTensor(),
                                    transforms.Normalize((0.5,), (1.0,))])
    dataset = MNIST(root='/path/to/mnist/', train=True, transform=transform,
                    download=True)
    loader = torch.utils.data.DataLoader(
        dataset=dataset,
        batch_size=self.batch_size,
        shuffle=True
    )
    return loader

# multiple dataloaders, return as list
def train_dataloader(self):
    mnist = MNIST(...)
    cifar = CIFAR(...)
    mnist_loader = torch.utils.data.DataLoader(
        dataset=mnist, batch_size=self.batch_size, shuffle=True
    )
    cifar_loader = torch.utils.data.DataLoader(
        dataset=cifar, batch_size=self.batch_size, shuffle=True
    )
    # each batch will be a list of tensors: [batch_mnist, batch_cifar]
    return [mnist_loader, cifar_loader]

# multiple dataloader, return as dict
def train_dataloader(self):
    mnist = MNIST(...)
    cifar = CIFAR(...)
    mnist_loader = torch.utils.data.DataLoader(
        dataset=mnist, batch_size=self.batch_size, shuffle=True
    )
    cifar_loader = torch.utils.data.DataLoader(
        dataset=cifar, batch_size=self.batch_size, shuffle=True
    )
    # each batch will be a dict of tensors: {'mnist': batch_mnist, 'cifar': batch_cifar}
    return {'mnist': mnist_loader, 'cifar': cifar_loader}

val_dataloader(num_images_per_class=50, add_normalize=False)[source]¶

Implement one or multiple PyTorch DataLoaders for validation.

The dataloader you return will not be reloaded unless you set reload_dataloaders_every_n_epochs to a positive integer.

It’s recommended that all data downloads and preparation happen in prepare_data().

fit()
validate()
prepare_data()
setup()

Note

Lightning adds the correct sampler for distributed and arbitrary hardware There is no need to set it yourself.

Return type: DataLoader
Returns: A torch.utils.data.DataLoader or a sequence of them specifying validation samples.

Examples:

def val_dataloader(self):
    transform = transforms.Compose([transforms.ToTensor(),
                                    transforms.Normalize((0.5,), (1.0,))])
    dataset = MNIST(root='/path/to/mnist/', train=False,
                    transform=transform, download=True)
    loader = torch.utils.data.DataLoader(
        dataset=dataset,
        batch_size=self.batch_size,
        shuffle=False
    )

    return loader

# can also return multiple dataloaders
def val_dataloader(self):
    return [loader_a, loader_b, ..., loader_n]

Note

If you don’t need a validation dataset and a validation_step(), you don’t need to implement this method.

Note

In the case where you return multiple validation dataloaders, the validation_step() will have an argument dataloader_idx which matches the order here.

STL-10¶

class pl_bolts.datamodules.stl10_datamodule.STL10DataModule(data_dir=None, unlabeled_val_split=5000, train_val_split=500, num_workers=0, batch_size=32, seed=42, shuffle=True, pin_memory=True, drop_last=False, *args, **kwargs)[source]¶

Bases: pytorch_lightning.core.datamodule.LightningDataModule

Warning

The feature STL10DataModule is currently marked under review. The compatibility with other Lightning projects is not guaranteed and API may change at any time. The API and functionality may change without warning in future releases. More details: https://lightning-bolts.readthedocs.io/en/latest/stability.html

Specs:

10 classes (1 per type)
Each image is (3 x 96 x 96)

Standard STL-10, train, val, test splits and transforms. STL-10 has support for doing validation splits on the labeled or unlabeled splits

Transforms:

transforms = transform_lib.Compose([
    transform_lib.ToTensor(),
    transforms.Normalize(
        mean=(0.43, 0.42, 0.39),
        std=(0.27, 0.26, 0.27)
    )
])

Example:

from pl_bolts.datamodules import STL10DataModule

dm = STL10DataModule(PATH)
model = LitModel()

Trainer().fit(model, datamodule=dm)

Parameters

data_dir¶ (Optional[str]) – where to save/load the data
unlabeled_val_split¶ (int) – how many images from the unlabeled training split to use for validation
train_val_split¶ (int) – how many images from the labeled training split to use for validation
num_workers¶ (int) – how many workers to use for loading data
batch_size¶ (int) – the batch size
seed¶ (int) – random seed to be used for train/val/test splits
shuffle¶ (bool) – If true shuffles the data every epoch
pin_memory¶ (bool) – If true, the data loader will copy Tensors into CUDA pinned memory before returning them
drop_last¶ (bool) – If true drops the last incomplete batch

prepare_data()[source]¶

Downloads the unlabeled, train and test split.

Return type: None

test_dataloader()[source]¶

Loads the test split of STL10.

Parameters

batch_size¶ – the batch size
transforms¶ – the transforms

Return type

DataLoader

train_dataloader()[source]¶

Loads the ‘unlabeled’ split minus a portion set aside for validation via unlabeled_val_split.

Return type: DataLoader

train_dataloader_mixed()[source]¶

Loads a portion of the ‘unlabeled’ training data and ‘train’ (labeled) data. both portions have a subset removed for validation via unlabeled_val_split and train_val_split

Parameters

batch_size¶ – the batch size
transforms¶ – a sequence of transforms

Return type

DataLoader

val_dataloader()[source]¶

Loads a portion of the ‘unlabeled’ training data set aside for validation.

The val dataset = (unlabeled - train_val_split)

Parameters

batch_size¶ – the batch size
transforms¶ – a sequence of transforms

Return type

DataLoader

val_dataloader_mixed()[source]¶

Loads a portion of the ‘unlabeled’ training data set aside for validation along with the portion of the ‘train’ dataset to be used for validation.

unlabeled_val = (unlabeled - train_val_split)

labeled_val = (train- train_val_split)

full_val = unlabeled_val + labeled_val

Parameters

batch_size¶ – the batch size
transforms¶ – a sequence of transforms

Return type

DataLoader
